Eisen CTL-27EVS Super High Precision Plain Turning Lathe (DV59-type)

Eisen Machinery


$ 15,495.00


Click here to be notified by email when this product becomes available.


Eisen CTL-27EVS Super High Precision Plain Turning Lathe (DV59-type)

  • Designed to machine precision small diameter parts.
  • Spindle runout within 50 millionths of an inch (0.0015mm).
  • Hardened and precision ground spindle mounted on high-precision preloaded angular contact ball bearings maximizes rigidity and sustained precision.
  • Stepless variable spindle speed provides desired speed on demand.
  • High quality YASKAWA variable frequency drive.
  • Fast lever collect closer allows chucking with one single movement.
  • Hardened and precision ground alloy steel bed ways resist wear.
  • Built-in coolant facilities with sump and self-draining oil pan.

CLT-27EVS Specifications

Capacity

DESCRIPTION CTL-27EVS
Spindle Capacity With Jaw Chucks 5”
With Expanding Collets 3”
With Round 5C Collets 11/6”
With Hexagon 5C Collets 7/8”
With Square 5C Collets 3/4”
With Step Chucks 11/16” ~ 6”
Length of Bed 36”
Swing over Bed 9”

Spindle

Spindle Nose Diameter Ø 2.189”
Spindle Nose I.D. / O.D. 5C Collet / 4° taper
Variable Spindle Speed w/ 5C Collet 0 ~ 4000 rpm
Variable Spindle Speed w/ 5” 3-Jaw Chuck 0 ~ 3000 rpm

Motor

Main Motor 3 HP, 220V, 3PH
(with Yaskawa variable frequency drive)
Coolant Pump 1/8 HP, 220V, 3PH

Dimensions

Net Weight 1000 lbs.
Gross Weight 1364 lbs.
Packing Dimensions Approx. (L X W X H) 74” x 35” x 68”
